FH30L
Features
●50 Acontactswitching capability
●Wecanprovidethecontactgapis 1.5 mm
●Contact arrangement:1 A､1 B､1 C
●Breakdown voltage(betweencoilandcontacts):4 KV
●Contactonandoffcanbecontrolledbymanualcontrolswitch
●ULinsulationsystem:Class F
●Environmental friendly product(Ro HS compliant)
●Outline dimensions:(39.0×15×30.2)mm
●Main application:Smart home,､Lightingcontrol
Description
Features
●50 Acontactswitching capability
●Wecanprovidethecontactgapis 1.5 mm
●Contact arrangement:1 A､1 B､1 C
●Breakdown voltage(betweencoilandcontacts):4 KV
●Contactonandoffcanbecontrolledbymanualcontrolswitch
●ULinsulationsystem:Class F
●Environmental friendly product(Ro HS compliant)
●Outline dimensions:(39.0×15×30.2)mm
●Main application:Smart home,､Lightingcontrol
For more application info or datasheet, pls contact us to get by mail.
Datasheet Preview
